Petrographic Thin Section Analysis

Thin section petrography is the foundation of interpretive Reservoir Quality Analysis. Statistics gathered during thin section analysis of whole core samples and drill cutting samples allow assessment of key factors including:

Rock fabric, composition and texture
Type, volume and distribution of grains, cements and clays
Grain size
Porosity, pore types and distribution
Paragenesis, diagenetic history and reservoir development
Cutoffs for reservoir quality assessment
Reservoir sensitivity
Completion recommendations
High quality thin section overview photographs and annotated high magnification photomicrographs

Highly porous Belloy Formation with bitumen (left) and multi-stage carbonate cemented Cardium Formation (right).

Optical microscope photographs of a petrographic thin section in plane polarized light (left) and cross-polarized light (right).
